Item# LCDT610D
This item is currently out of stock!

Universal RF Coax Composite Video To HDMI VGA Converter Switch
This external analog cable TV tuner package doubles as a video up-converter and switcher. Mainly designed to work with analog coax TV signals such as cable TV or satellite channels, closed circuit TV channels or other RF modulated signals by converting such coax feeds into high resolution HDMI or VGA formats for visual entertainment or further A/V broadcast and distribution.

With the help of advanced video processor built in, this coax TV channel converter delivers outstanding 1080p HDMI or 1920x1200 pixels DVI or VGA format with astonishing digital video quality that surpasses regular TV displays for visual entertainment.

This multi-function TV tuner system consists of 2 main components, TV tuner module + VGA to HDMI converter module. Either one of them can be used as a standalone video converter/switch or cascaded with other video equipments such video mixer, video switch or video splitter to form a large-scale display system. This unit fits various applications such as:

  • Classrooms, training center and conference room
  • Public video broadcasting such as air ports, train stations, retail stores
  • Media control rooms and multimedia center
  • Tradeshows, hospitals, auditorium and command rooms
  • Digital signage

TV channel or video input source selection and other functions can be controlled by using the supplied IR remote or push buttons on the unit. Manual buttons are for basic functions like power on/off, video input selection, TV channel up/down and volume control. Advanced features like POP, Mute, Menu and so on are available through the IR remote.

Simply connect all of your video sources thru this unit via coax cable, composite RCA, s-video and VGA cable and select the desired input for display on any LCD monitor/projector or flat panel VGA-based display with supreme picture quality.

This device supports multiple video signal inputs from:Application Setup Diagram For Ambery LCDT610

  • RF or coax feeds for analog cable TV, private close-circuit channels, legacy game consoles or other modulated systems.
  • set-top boxes with coax out such as cable box, satellite receiver, DVR, etc.
  • digital media player such as DVD or signage player
  • video camera such as camcorder or surveillance camera
  • game consoles such as PS2, PS3, Xbox, Wii, etc.
  • desktop/laptop PC or CCTV DVR
  • all other composite video sources such as DVR, A/V receiver, etc.

The operation of this multimedia video converter switcher unit is all hardware operation. Easy cable hookup and no software drivers needed. Operated by either IR remote controller provided or manual push buttons on the unit.

Universal Analog TV Tuner With HDMI VGA Output
The RF input of this TV tuner converter supports worldwide analog RF TV channel frequencies and standards including NTSC, PAL B/G/D/K/I, PAL M/N and SECAM.

It works for all regions in the world and able to decode all standard UHF, VHF and analog cable TV channels within the range of 48.25 to 883.25MHz.

This tuner can provide total of 10 different HDMI/DVI and VGA output resolutions including:

  • 1920x1200 pixels (VGA)
  • 1080p (HDMI,DVI)
  • 1920x1080 pixels (DVI,VGA)
  • 1680x1050 pixels (VGA)
  • 1440x900 pixels (VGA)
  • 720p (HDMI,DVI)
  • 1280x720 pixels  (DVI,VGA)
  • 1280x1024 pixels (VGA)
  • 1024x768 pixels (VGA)
  • 800x600 pixels (VGA)

RF Coax CATV Channel Demodulator
This TV video converter switch is an easy add-on tuner module for those LCD monitors projectors that do not have TV tuner built in or LCD TV with broken RF terminals. It can demodulate the RF outputs from all coax video sources such as cable set top boxes, video modulators, surveillance DVR systems and so on.

This RF TV demodulator can also be used for those satellite receivers with modulated TV2 out from DirecTV, Dish Network and all other Free-To-Air set top boxes for all regions. Please make sure that the coax output from your satellite set top box can be displayed on channel 3, 4 or other TV channel or contact your satellite TV provider for verification.

Multi-Format Analog Video To HDMI VGA Scaler Switcher
This multi-function TV video converter system supports total of 4 video inputs including coax, composite RCA, S-Video and VGA Input. It expands the HDMI or VGA display with video/audio inputs like what a TV has. Users can connect various video devices together into this unit with no hassles of changing cables and convert the selected video input into high resolution HDMI or VGA signal with optimized image quality for display.

This unit is great for various applications including:

  • RF Coax CATV To HDMI VGA: decode the UHF/VHF air channels, analog cable TV channels or the satellite coax output to 1080p/720p HDMI or 1920x1080/1920x1200 VGA pixels for display.
  • Composite RCA S-Video To HDMI VGA: up-convert composite RCA or S-Video to 1080p/720p HDMI or 1920x1080/1920x1200 VGA pixels for display.
  • Audio/Video Switch: easy IR remote control for selecting desired RF TV signal or standard video signal from sources connected for presentation in classroom, tradeshow or personal visual entertainment.

Real-Time Picture-In-Picture Video ProcessorPicture-In-Picture Support For Super Video To WSXGA Converter + External Cable TV Tuner
This unit supports VGA pass-through for hookup with VGA output from computer or DVR. This allows users to use a regular LCD monitor or projector to display TV channel, DVD movie, surveillance cam or video game while using computer for internet or other tasks at the same time on one screen, typically known as picture-in-picture (PIP).

With all its advanced PIP features provided, users can enjoy using computer and watching TV shows or surveillance cam simultaneously on the same screen so never miss a show or a move.

The available PIP control functions includes:

  • PIP Input Selection: Select the desired input video source (TV channel or RCA/S-Video) to be displayed on the video sub-window on the monitor.
  • PIP Size: Users can re-size the PIP video window screen at 1/16, 1/9, 1/4 and up to full screen for display.
  • PIP Location: The PIP video window can be moved around the computer screen to any desired position. The horizontal and vertical position adjustment are available through using the IR remote.

Advanced Video Processor Engine
With image enhancement technologies implemented, this converter produces greater detail for a more true-to-life image. Advanced features include:

  • Digital color luminance improvement to enhance image definition for crisp and clear images
  • Digital transient improvement to reduce color smear for true and brilliant color definition
  • Advanced color space conversion with smooth motion picture enhancement
  • Adaptive non-linear noise filter to reduce interference between pixels
  • Superior video quality with 3:2/2:2 pull-down recovery to remove jitters

Internal Speaker
The audio output of this TV video converter can be played directly through its internal speaker or routed through its 3.5mm audio port for hookup with multimedia speakers or home stereo system.

And the volume level or TV channel up/down can be controlled via the IR remote or the push buttons on the unit.

Last Memory
This video image processor will memorize users' settings in the system buffer once configured or adjusted. The previous PIP screen mode will be displayed right away in the same configuration after power cycling or power outage. No need to configure again for the desired screen mode again after the power-off or outage.

Daisy Chain Setup
This PIP video generator can be used as standalone unit or cascaded together to process more video inputs or combined with other video mixers or A/V switches to form a large display system, great video module for professional installers for expanding current client's setup at any stage.

  • Universal TV tuner design supports worldwide RF frequencies for all NTSC, PAL B/G/D/K/I, PAL-M, PAL-N, SECAM systems.
  • Easy add-on TV tuner module for all LCD TV, flat panel monitor or projector without coax input.
  • Decoding RF coax signals from cable outlet, satellite box, RF modulator or CCTV surveillance camera system to digital HDMI signal or sharp VGA pixels for display.
  • 4 selectable video inputs: RF/Coax, RCA A/V, S-Video and VGA pass through.
  • 2 selectable VGA and HDMI output formats.
  • Excellent video to HDMI + VGA converter for converting interlaced video into HDMI or progressive VGA type for great video clarity and sharpness.
  • Selectable 10-level HDMI and VGA output resolutions with maximum output up to 1080p HDMI or 1920 x 1200 VGA pixels.
  • Supports Picture-In-Picture function for watching cable TV or video from a sub-window while the compute takes the main screen.
  • PIP TV video sub-window can be resized from 1/16, 1/9, 1/4 screen or full screen display.
  • PIP window screen location can be re-positioned to anywhere on the monitor screen if needed.
  • Premium motion adaptive de-interlacer built in for minimizing jagged edges noticed on big screen.
  • Provides crisp and clear images with true and brilliant color definition.
  • Adjustable controls of video color elements for brightness, contrast, hue, saturation, color temperature and picture modes.
  • Supports all NTSC and PAL systems with automatic video mode detection.
  • Support sleep timer from 10 - 120 minutes for automatically turning off the module.
  • Full-function IR remote controller.
  • Featured with internal speaker for direct audio output.
  • Easy operation by IR remote provided or manual push buttons on the converter unit.
  • Used as standalone video switch or TV video unit or cascaded with other video equipments such video mixer, video switch or video splitter.
  • Compact and stylish design.

  • TV Tuner Type: Universal Type for all NTSC, PAL B/G/D/K/I, PAL-M, PAL-N, SECAM systems
  • 4 Video Inputs:
    • Video 1 Input: Coaxial (RF) for TV tuner input
    • Video 2 Input: Composite RCA video Input
    • Video 3 Input: S-Video Input
    • Video 4 Input: PC VGA input via mini Din adapter cable
  • 2 Video Outputs: HDMI + VGA 15 pin D-sub
  • 2 Audio Inputs:
    • Audio 1 Input: Composite RCA L/R connectors for RCA or S-Video input
    • Audio 2 Input: 3.5 mm stereo phone jack x 1 for PC VGA input
  • Audio Output: 3.5 mm stereo phone jack x 1
  • Video Output Resolutions:
    • 1920x1200 pixels (VGA)
    • 1080p (HDMI,DVI)
    • 1920x1080 pixels (DVI,VGA)
    • 1680x1050 pixels (VGA)
    • 1440x900 pixels (VGA)
    • 720p (HDMI,DVI)
    • 1280x720 pixels  (DVI,VGA)
    • 1280x1024 pixels (VGA)
    • 1024x768 pixels (VGA)
    • 800x600 pixels (VGA)
  • Video Adjustment  Support: Brightness, Contrast, Color, Hue, Sharpness, Tint
  • TV Audio Support: stereo, mono, mute
  • Power Supply: 110V-240V AC input with DC 5V 1A out, center positive

  • TV video converter/tuner unit
  • VGA to HDMI scaler
  • IR remote controller
  • 5V DC switching power adapter (US plug)
  • coax adapter
  • VGA input adapter cable
  • 3.5mm stereo cable
  • Vertical stand
  • User manual
