4 In 1 Out Composite Video Switcher

4 In 1 Out Composite Video Switcher
4 In 1 Out Composite Video Switcher
Item# RCASW-4P
$19.00

4 In 1 Out Composite Video Switch4 In 1 Out Composite Video Switch
This 4-port composite video switcher is the perfect solution for anyone who needs to send four sources of high quality composite video to a single display such as a TV , video monitor or video recorder without disconnecting and reconnecting the cables.

It is designed for ease of operation and maintenance setup. Also beneficial for reducing the wear and tear on the input connector of your video monitor caused by daily operations when constantly plugging and unplugging the composite video cables.

This video switch comes with easy rotary dial for switching between multiple composite type video signal inputs from standard video devices such as making this unit the perfect application for switching signals between VCR/DVD players, camcorders, CCTV surveillance cameras, DVR, video game consoles, satellite receivers, etc.

Users can select either one of the 4 composite video sources connected for output display by simply turning the dial on the front panel so the desired source input signal can be routed to a regular display such as TV monitor, TV, video projector etc.

This 4-port composite video switcher is is a passive switching device so no external power supply needed.

Front And Back Panel Of 4 In 1 Out Composite Video Switch Application Diagram For 4 In 1 Out Composite Video Switch

  • Supports multiple video inputs for up to 4 composite video sources.
  • Fast switching between video inputs using rotary dial on the front panel.
  • Works with all standard video devices such as VCR/DVD players, camcorders, CCTV surveillance cameras, DVR, video game consoles, satellite receivers, etc. with composite video connectors.
  • Reducing the wear and tear on the input connector of your video monitor caused by daily operations when constantly plugging and unplugging the video cables.
  • Designed for ease of operation and maintenance setup.
  • Easy rotary knob for input source selection from the front panel.
  • Easy to install and simple to operate.
  • Rugged metal enclosure provides EMI/RFI shielding.
  • Passive switching device with no external power supply needed.

  • Supports standard composite video at 75 ohm
  • Inputs: composite RCA female connector x 4
  • Output: composite RCA female connector x 1
